Polwax PTRANS T10
Features:
✔ Wide Temperature Range
✔ High Accuracy
✔ Large Data Storage
✔ USB Interface
✔ Cost-Effective Single Use Solution
✔ Durable and Robust Design (IP68)
Single Use Temperature Datalogger PTRANS-T10
This product is a single-use, configurable, and battery-replaceable temperature data logger. This logger has an that allows you to view temperature data. It is mainly used to monitor and record the temperature data of food, fresh produce, medicine, and other products during storage and transportation. It is widely used in aspects of warehousing and logistics cold chains, such as refrigerated containers, refrigerated trucks, refrigerated bags, cold storage, laboratories, etc.
The Polwax PTRANS-T10 Single Use Temperature Datalogger is a state-of-the-art solution designed for precise and reliable temperature monitoring in industries such as pharmaceuticals, food transportation, and cold chain logistics. This compact device is engineered for one-time use, making it an economical choice for applications requiring secure and disposable temperature tracking. With a temperature range of -30°C to 70°C and an impressive accuracy of ±0.5°C, the PTRANS-T10 ensures that your sensitive goods are transported and stored under optimal conditions. Its substantial data memory of 33,000 readings guarantees uninterrupted recording throughout the monitoring period, providing detailed and comprehensive temperature data.
This datalogger features a USB interface, allowing users to easily connect it to a computer to retrieve data. The inbuilt software automatically generates PDF reports, offering a user-friendly way to analyze and document temperature data without requiring additional software installation. For more advanced data management needs, the device also supports CSV file generation. Configuration is made simple with its web-based software, enabling users to set parameters such as start delay, interval, and alarm thresholds to suit specific requirements.
Durability is at the core of the Polwax PTRANS-T’s design. With an IP68 waterproof rating, the datalogger is well-suited for use in demanding environments, offering reliable performance even under challenging conditions. The non-replaceable battery ensures a robust single-use design, eliminating concerns about maintenance or battery life. Additionally, the device is supplied in a sealed plastic pouch, ensuring hygiene and safety in handling, which is especially critical for applications in the food and pharmaceutical sectors.
Technical Data
Technical Specifications
Display
Without Display
Accurary
±0.4°C@-10~40℃，±0.8℃@-30~-10℃&40~70℃
Measuring Range
-30 to 70°C
Protection Class
IP68
Dimensions
70*33*7mm
Language
English
Resolution
0.1°C
Memory Space
Up to 33,000 points
Weight
23g
Alarm Limit
Up to 2 individually programmable alarm limits
Logging Interval
1 minute -24 hours optional（Default 5 minutes）
LED Indicator
Green（Recording，OK），Red（Alarm），Yellow（Start Delay）
Battery life
Up to 2 years（ 1 year storage / 1 year useful life）@25℃，5 minutes logging interval
Start Delay
0 minute -24 hours optional（Default 10 minutes）
Start Mode
Manual start
Battery Type
3.0V CR2450
Certification
CE，EN12830:2018，RTCA/DO-160G，RoHS
Connection
USB2.0
Report Format
PDF/CSV/PDF&CSV(Optional, configured before leaving the factory)
Scope of Supply
Datalogger with Sealed Plastic Pouch, Test Certificate, Instruction Manual
Configuration Software Link
http://config.polwax.it/
APPLICATIONS
The POLWAX PTRANS-T10 Single Use Temperature Datalogger is specifically designed for temperature-sensitive logistics, offering a reliable and cost-effective solution for single-trip monitoring. It is widely used in various industries where cold chain integrity is critical. Typical applications include:
-
Pharmaceuticals and Vaccines – Ensures temperature compliance during storage and transit of medicines, vaccines, and biotech products.
-
Food & Beverage – Monitors perishable goods such as dairy, meat, seafood, frozen foods, and fresh produce during distribution.
-
Clinical Trials and Laboratories – Tracks environmental conditions for sensitive biological samples and test materials.
-
Chemical Shipments – Monitors temperature-sensitive chemicals and reagents in industrial and research sectors.
-
Floral and Horticulture – Maintains freshness of flowers, plants, and seeds during long-distance shipments.
-
Logistics and Warehousing – Used by freight forwarders, logistics providers, and warehouse operators to ensure proper handling and regulatory compliance.
Supply/ Delivery Scope
The POLWAX PTRANS-T10 Single Use Temperature Datalogger is supplied as a ready-to-use, compact USB device with integrated sensor and internal battery. Each unit comes pre-configured with a default logging interval and alarm thresholds, making it suitable for immediate deployment in cold chain logistics. The device is individually packed and labeled, ensuring traceability and easy identification. Upon delivery, users receive access to free downloadable software for data analysis and PDF report generation, eliminating the need for external hardware or specialized tools. The datalogger is disposable after one-time use and complies with international standards for temperature-sensitive shipments, ensuring safe and reliable monitoring throughout the transit.
